01.Vehicles are allowed to pass on both the left side of the road and the right side of the road.

02.Application scope: Highway, viaduct, bridge and tunnel intersection.

03.Product shape: 6mm thickness super slim shape.

Solar panels	Items	Spec
	Generating unit	Single crystal silicon solar panel
	Voltage	6.8 V
	Electric current	420mA
Storage unit	Items	Spec
	Storage unit	SANYO high capacity lithium battery
	Battery voltage	3.7 V
	Battery capacity	10400Ma
Light emitting unit	Items	Spec
	Light emitting unit	LED
	Light color	Optional
	LED quantity	One hundred and twenty
	Lighting time	Daytime 400Lux , Night 100 Lux (On demand)
Light emitting unit	Items	Spec
	Product size	1200mm X 800mm X 6mm
	Shell material	PC, stainless steel, paint, Aluminum Alloy
	Water proof	Level 6
	Sight distance	Visible distance up to 300 meters
	Standby	Up to 100 hours
	Working temperature	-40℃～75℃
	Weight	14kg

01.Product usage:Warning for the intersectionahead, paying attention to the vehicle.

02.Application scope: This sign is setat the intersection.

Solar panels	Items	Spec
	Generating unit	Single crystal silicon solar panel
	Voltage	6.8 V
	Electric current	420mA
Storage unit	Items	Spec
	Storage unit	SANYO high capacity lithium battery
	Battery voltage	3.7 V
	Battery capacity	10400Ma
Light emitting unit	Items	Spec
	Light emitting unit	LED
	Light color	Optional
	LED quantity	Ninety
	Lighting time	Daytime 400Lux , Night 100 Lux (On demand)
Light emitting unit	Items	Spec
	Product size	500mm X 500mm X 60mm
	Shell material	PC, stainless steel, paint, Aluminum Alloy
	Water proof	Level 6
	Sight distance	Visible distance up to 300 meters
	Standby	Up to 100 hours
	Working temperature	-40℃～75℃
	Weight	16kg
